Description of NeoDen IN6
NeoDen IN6 is a newly designed, environmentally friendly reflow oven with stable performance.
It can achieve full hot-air convection, excellent soldering performance.
It has 6 temperature zone, light and compact. Intelligent temperature control with high sensitivity temperature sensor, temperature can be stable within ±0.2°C.
It adopts Japan NSK hot air motor bearing and Swiss imported heating wire, which is durable and stable.
CE approved, provide authoritative quality assurance.
NeoDen IN6 parameters
| Heating/Temperature Control System | Number of Heating Zones: 6 Zone Design (3 upper / 3 lower) |
| Heating Type: Full Hot Air Convection, Nickel-Chromium Wire and Aluminum Alloy Heating | |
| Number of Cooling Zones: 1 | |
| Temperature Control Range: Room temperature ~ 300 ℃ | |
|
Temperature Control Accuracy: ±0.2 ℃ |
|
| Temperature Distribution Deviation: ±1 ℃ | |
| Heat-up Time: Approx. 20-30 minutes | |
| Capacity/Process Parameters | Soldering Width: 260 mm (10 inches) |
| Process Chamber Length: 680 mm (26.8 inches) | |
| Standard Max Height / Max Assembly Clearance: 30 mm (1.2 inches) | |
| Conveyor System |
Conveyor Speed: 5 - 30 cm/min (2 - 12 in/min) |
|
Conveyor Belt Type: Stainless-steel springwire conveyor belt |
|
|
Electrical Specifications |
Power Requirement/Supply: 110/220VAC Single Phase |
|
Power Max / Max Rated Power: ~ 2KW |
|
|
Working Power: ~ 700W |
|
|
Physical Specifications |
Dimensions (L*W*H): 1020 * 507 * 350 mm |
|
N.W./G.W.: 49KG / 64KG (excluding workbench) |
|
|
Packing Dimensions: 1120*620*560 mm |
Our Service
1. Good knowledge on different market can meet special requirements.
2. Real manufacturer with our own factory located in Huzhou, China.
3. Strong professional technical team ensure to produce the top quality products.
4. Special cost control system ensure to provide the most favorable price.
5. Rich experience on SMT area.
6. Provide product instructions, YouTube video tutorials, experienced after-sales technicians, 24 hours online service.
7. With our own manufactory and more than 10 years of experience in SMT industry, we can provide customers with the most cost-effective products.
About NeoDen
Factory
Company Profile
Zhejiang NeoDen Technology Co., LTD., founded in 2010, is a professional manufacturer specialized in SMT pick and place machine, reflow oven, stencil printing machine, SMT production line and other SMT Products. We have our own R & D team and own factory, taking advantage of our own rich experienced R&D, well trained production, won great reputation from the world wide customers.
In this decade, we independently developed NeoDen4, NeoDen IN6, NeoDen K1830, NeoDen FP2636 and other SMT products, which sold well all over the world. So far, we have sold more than 10,000pcs machines and exported them to over 130 countries around the world, establishing a good reputation in the market. In our global Ecosystem, we collaborate with our best partner to deliver a more closing sales service, high professional and efficient technical support.
We believe that great people and partners make NeoDen a great company and that our commitment to Innovation, Diversity and Sustainability ensures that SMT automation is accessible to every hobbyist on everywhere.
Exhibition
Certification
FAQ
Q1. How can I buy machine from you?
A: (1) Consult us on line or by e-mail.
(2) Negotiate and confirm the final price, shipping, payment method and other terms.
(3) Send you the proforma invoice and confirm your order.
(4) Make the payment according to the method put on proforma invoice.
(5) We prepare your order in terms of the proforma invoice after confirming your full payment. And 100% quality check before shipping.
(6) Send your order via express or by air or by sea.
Q2. This is the first time I use this kind of machine, is it easy to operate?
A. Yes. There are English manual and guide video that show you how to use machine.
If there is any doubt in the process of operating the machine, please feel free contact us.
We also provide overseas on-site service.
Q3. Are you a trade company or a manufacturer?
A. We are an professional manufacturer specialized in SMT Machine, Pick and Place Machine, Reflow Oven, Screen Printer, SMT Production Line and other SMT equipments.
Hot Tags: bench top smt reflow oven, China bench top smt reflow oven manufacturers, suppliers, factory
