What Is A Solder Paste Printer?
A solder paste printer is a machine used in electronic manufacturing to apply precise and consistent solder paste onto a PCB through a stencil. It is a crucial step in the Surface Mount Technology assembly process, ensuring components will be properly soldered in place. Modern printers range from manual tabletop models to fully automated systems with features like automatic alignment, pressure control, and quality inspection.
paramenters of NeoDen Solder paste printer
| products |
|
|
|
|
|
| Model | NeoDen FP2636 | neoDen YS Series | NeoDen ND450 | neoDen ND1 | NeoDen ND2 |
| Used for | Prototype/Entry-Level | Flexible/Medium-Batch | High-Speed/Specialized | High-Speed/Specialized | High-Speed/Specialized |
|
Max PCB Size |
280 * 380mm |
YS350: 400 * 240mm YS600: 600 * 240mm YS1200: 1200 * 240mm |
450 * 350mm | 450 * 350mm | 450 * 350mm |
| Printing Area |
260 * 360mm |
YS350: 500 * 320mm YS600: 700 * 320mm YS1200: 1300 * 320mm |
550 * 650mm |
737 * 737mm |
737 * 737mm |
|
PCB Thickness |
0 - 20mm |
0.2 - 2.0mm |
0.4 - 4mm |
Automatic adjustment |
Automatic adjustment |
|
Repeatability |
± 0.01mm |
± 0.2mm |
± 0.025mm |
± 25 microns |
± 20 microns |
|
Dimension |
660 * 470 * 245mm |
YS350: 800 * 700 * 1700mm YS600: 900 * 700 * 1700mm YS1200: 1600 * 700 * 1700mm |
992 * 1305 * 1430mm |
1140 * 1400 * 1480mm |
1152 * 1415 * 1540mm |
FAQ
Q: What type of solder paste printer is the NeoDen FP2636?
A: The NeoDen FP2636 is a manual solder paste printer , designed for small-scale production, prototyping, and R&D environments.
Q: What type of stencil does the NeoDen FP2636 SMT stencil printer supports?
A: It supports frameless stencil.
Q: Can we make the stencils locally?
A: Yes, this printer's stencil support customers DIY its dimension and very convenient to make it locally.
Q: Can we change it to framed type later?
A: Yes, it is workable, but an upgrade package will be needed.
Q: What's the Max PCB size supported?
A: The NeoDen FP2636 supports PCBs up to 260 x 360 mm in size.
NeoDen Solder Paste Printer: Precision Solutions from Prototyping to Volume Production
Manual/Prototyping: Cost-Effective Entry-Level Precision
1. Exceptional Cost Efficiency
Offers the most competitive pricing in the market, significantly reducing startup costs—ideal for startups and R&D labs.
Rapid ROI: Achieve precise printing on a low budget, accelerating product iteration.
2. Precision Micro-Adjustment Mechanism
Features X/Y/Z-axis micro-adjustment knobs for precise positioning of PCBs and stencils, ensuring high repeatability in printing.
Quality Assurance: Even as a manual device, it achieves high-precision alignment, minimizing misalignment risks.
Semi-Automatic: The Cornerstone of Stable, Reliable Productivity
1. Optimized Printing Quality
An optimized squeegee system ensures uniform printing pressure, delivering stable and consistent solder paste deposition.
Defect Reduction: Eliminates human-induced variability, guaranteeing consistent solder paste thickness and placement.
2. Flexible Clamping System
Adopts an efficient clamping system that rapidly adapts to different PCB sizes, enhancing line change efficiency.
Production Flexibility: Effortlessly handles multi-variety, small-batch order demands.
Automatic: Fully Automatic High Precision and Intelligent Production
1. High-Precision Vision Alignment
Equipped with a high-resolution CCD vision system, enabling fully automatic, precise alignment of PCBs with stencils (X/Y/θ axes), supporting fine-pitch component printing.
Ultimate Yield: Eliminates human alignment errors, ensuring precise solder paste placement, particularly suitable for miniaturized components.
2. Closed-Loop Intelligent Control
Utilizes high-performance servo motors to achieve precise closed-loop control of squeegee stroke, speed, and pressure, ensuring printing process stability and repeatability.
Process Stability: Highly controllable printing parameters significantly enhance production yield and consistency.
3. Robust Operating System
Intuitive user interface and powerful operating system enable simple, efficient operation with parameter storage and quick recall.
Efficient and User-Friendly: Reduces operator training time while enabling rapid setup and production task switching.
- Global Technical Support & Warranty: Our equipment serves over 130 countries/regions worldwide, backed by reliable warranty coverage and lifetime technical support.
- Rapid Response Mechanism: Our professional engineering team guarantees customer response within 8 hours and delivers expert solutions within 24 hours, ensuring uninterrupted production.
As one of the leading solder paste printer manufacturers and suppliers in China, we offer a wide range of products with superior quality. Please feel free to buy high-grade solder paste printer at competitive price from our factory. Thank you for your interest in our products.
