Manual Frameless Stencil Printer

● ±0.01 mm Repeatability
● 1 mm fine pitch (Min)
● 280 x 380 mm PCB size (Max)

A powerful tool for efficient, low-cost SMT prototyping and small-to-medium batch printing.
NeoDen FP2636 Manual Frameless Stencil Printer is a high-precision, highly flexible manual SMT solder paste printer. This provides users with an efficient and cost-effective printing solution, making it ideal for prototyping and small-to-medium volume SMT production.

NeoDen FP2636 Overview

Brand and Model: NeoDen FP2636 Frameless

Application Areas: Suitable for SMT applications including prototyping, small-batch production, and educational research.

Core Advantages: High precision, flexible operation, compatible with framed/frameless stencils, excellent cost-performance ratio.

Highlights and Details

High-Precision Positioning and Leveling

Precision T-screw adjustment: Ensures adjustment accuracy and levelness of the PCB mounting plane.

3D micro-adjustment system: Equipped with X, Y, and angle adjustment handles for precise alignment between the stencil and PCB.

±0.01mm repeat positioning: Guarantees consistent print quality with every operation.

Exceptional Operational Convenience

Straight-damping shaft design: Screen clamping frame locks securely at any angle for enhanced usability.

Intuitive lettering: Adjustment handles feature letter markings for straightforward operation.

Reference scale ruler: Alignment guide on screen clamping frame ensures level positioning.

Adjustable rubber feet: Maintain stable, level operation on work surfaces.

NeoDen FP2636 Multi-functional PCB Clamping

Flexible PCB and Stencil Compatibility

Multi-functional PCB Clamping: Utilizes L-shaped brackets and positioning pins to secure PCBs, accommodating various PCB types.

Frameless Stencil Support: Provides a mechanical clamping frame for rapid installation and replacement of frameless stencils, delivering efficiency and cost savings.

Single/Double-Sided PCB Support: Capable of printing on both single-sided and double-sided PCBs.

Products Description

Equipment Dimensions	594×382×187 mm
Max. PCB Size	280×380 mm
PCB Thickness	0~20 mm
Platform Height	190 mm
Repeatability	±0.01 mm
Fine Adjustment Range	X-axis ±15mm, Y-axis ±15mm, Z-axis ±15mm
Net Weight	12 Kg

Commercial Information

MOQ: 1 pc

Packaging Details: Carton packaging

Delivery Time: In stock
