Highlights
- Built-in welding fume filtration system, effective filtration of harmful gases, beautiful appearance and environmental protection, more in line with the use of high-end environment.
- The control system has the characteristics of high integration, timely response, low failure rate, easy maintenance, etc.
- Unique heating module design, with high precision temperature control, uniform temperature distribution in the thermal compensation area, high efficiency of thermal compensation, low power consumption and other characteristics.
- Unique heating plate design effectively ensures uniform cooling after the equipment stops heating, effectively preventing the parts from being damaged by the rapid decrease in temperature and the resulting deformation.
- The internal temperature box is made of stainless steel, which is environmentally friendly and odorless, and the inner side is equipped with heat insulation cotton to effectively prevent heat loss.
- Concealed screen design is convenient for transportation, easy to use, beautiful and generous.
- The control system uses imported chips, temperature control accuracy of ± 0.5%
- All temperature zones and cold air zone wind speed adjustable, easily cope with a variety of welding needs.
- Automatic limit after the top cover is opened, effectively ensure production safety.
Products Description
| Heating/Temperature Control System |
Number of Heating Zones: 12 Zone Design (6 upper / 6 lower) |
|
Heating Type: Hot Air Convection |
|
|
Heating Element: High-Performance Aluminum Alloy Heating Plate (Non-Traditional Heating Tubes) |
|
|
Temperature Control Range: Room temperature ~ 300 ℃ |
|
|
Temperature Measurement System: Professional 4-channel real-time PCB surface temperature monitoring |
|
|
Heat-up Time: Approx. 30 minutes |
|
|
Capacity/Process Parameters |
Maximum PCB Width: 300 mm |
|
Solder Fume Treatment: Built-in solder fume filtration system |
|
|
Max Height: Top 30mm / Bottom 15mm |
|
|
Conveyor System |
Conveyor Speed: 50 - 600 mm/min |
|
Conveyor Type: Rail |
|
|
Track Direction: Left to Right |
|
|
Electrical Specifications |
Power Supply: 220V |
|
Typical Working Power: Approx. 2.2KW |
|
|
Physical Specifications |
Equipment Dimensions (L*W*H): 2300 * 900 * 1300 mm |
|
Net Weight: 300 KG |
Our Services
1. More Professional service in PNP machine field.
2. Better manufacture ability.
3. Various payment term to choose: T/T, Western Union, L/C, Paypal.
4. High quality/Safe material/Competitive price.
5. Small order available.
6. Quickly response.
7. More safe and fast transport.
About NeoDen
Factory
Quick facts about NeoDen
Zhejiang NeoDen Technology Co., LTD., founded in 2010, is a professional manufacturer specialized in SMT pick and place machine, reflow oven, stencil printing machine, SMT production line and other SMT Products. We have our own R & D team and own factory, taking advantage of our own rich experienced R&D, well trained production, won great reputation from the world wide customers.
- We are in a good position not only to supply you high quality pnp machine, but also the excellent after sales service.
- Well-trained engineers will offer you any technical support.
- 30+ engineers powerful after-sales service team can respond customers queries and enquiries within 8 hours.
- Professional solutions can be offered within 24 hours both workday and holidays.
FAQ
Q1. What about the lead time for mass production?
A: Honestly, it depends on the order quantity and the season you place the order.
Always 15-30 days based on general order.
Q2. What is your terms of delivery?
A: We accept EXW, FOB, CFR, CIF, etc.
You can choose the one which is the most convenient or cost effective for you.
Q3. When did your factory established?
A: Since 2010
Q4. How many square meters of your factory?
A: More than 27,000 square meter.
Q5. How many workers in your factory?
A: More than 200 workers.
