Description of NeoDen S1 SPI inspection Machine
1. High Performance and Precision Inspection
- High-speed inspection: Processing time per frame is less than 0.7 seconds.
- High precision: Height detection precision is 1 μm, and repeatedly (volume, area, height) is less than 1 μm@3sigma.
- Comprehensive function: It can check for various solder paste defects, including area, volume, height, shape, offset, and continuous tin electrodeposit.
2. Stable Mechanical System with Wide Compatibility
- Efficient transfer: Transfer speed is up to 1500mm/s (MAX) and matches SMEMA.
- Strong compatibility: It supports a wide range of PCB sizes, from a minimum of 50mm×50mm to a maximum of 500mm×460mm, with a thickness range of 0.6mm to 6mm.
- Precise movement: The X/Y platform is driven by an AC servo motor system with a setting accuracy of less than 1 μm.
NeoDen S1 SPI Parameter
| Check System | Camera: 5 mega-pixel |
| Lighting: Surrounded RGB | |
| FOV: 42 × 34mm (17 μm) | |
| Processing time per frame: < 0.7 seconds | |
| Max test height: 450 μm | |
| Solder scope: 0.2 ×0.2 mm ～ 12 × 12 mm | |
| Performance Metrics | Height detection precision: 1 μm |
| Volume/Area/Height Repeatability: < 1 μm @3sigma | |
| Repeatability & Reproducibility (R&R): < 10% | |
| Software Features | Operating System: Windows 10 64-bit |
| Operating Interface: Graphical programming, Chinese/English language switching | |
| Programming Support: Supports Gerber, CAD input, offline and manual programming | |
| SPC Support: Offline SPC / Real-time reporting (Anytime Report) | |
| Data Export: Excel, Images (jpg, bmp) | |
| Mechanical & Transfer | PCB Transfer Height: 900 ± 30 mm |
| Substrate Fixing Mode: Edge Lock Plate | |
| Min PCB Size: 50 × 50 mm | |
| Max PCB Size: 500 × 460 mm | |
| Transfer Speed: 1500 mm/s (Max) | |
| Platform System | Driver Equipment: AC servo motor system |
| X/Y Platform Setting Accuracy: 5μm | |
| Moving Speed: 600 mm/s |
Our Services
1. Good knowledge on different market can meet special requirements.
2. Real manufacturer with our own factory located in Huzhou, China.
3. Strong professional technical team ensure to produce the top quality products.
4. Special cost control system ensure to provide the most favorable price.
5. Rich experience on SMT area.
6. Provide product instructions, YouTube video tutorials, experienced after-sales technicians, 24 hours online service.
7. With our own manufactory and more than 15 years of experience in SMT industry, we can provide customers with the most cost-effective products.
About NeoDen
Factory
Company Profile
Zhejiang NeoDen Technology Co., Ltd. has been manufacturing and exporting various small pick and place machines since 2010. Taking advantage of our own rich experienced R&D, well trained production, NeoDen wins great reputation from the world wide customers.
In our global Ecosystem, we collaborate with our best partners to deliver a more closing sales service, high professional and efficient technical support.
We believe that great people and partners make NeoDen a great company and that our commitment to Innovation, Diversity and Sustainability ensures that SMT automation is accessible to every hobbyist everywhere.
1) Established in 2010, 200 + employees, 27000+ Sq.m. factory.
2) NeoDen Products:Different Series PnP machines, NeoDen YY1, NeoDen4, NeoDen5, NeoDen K1830, NeoDen9, NeoDen N10P. Reflow Oven IN Series, as well as complete SMT Line includes all necessary SMT equipment.
3) Successful 10000+ customers across the globe.
4) 40+ Global Agents covered in Asia, Europe, America, Oceania and Africa.
Exhibition
Certification
FAQ
Q1. Which payment form you can accept?
A: T/T, Western Union, PayPal etc.
We accept any convenient and swift payment term.
Q: What's is your shipping service?
A: We can provide services for vessel booking, goods consolidation, customs declaration, shipping documents preparation and delivery bulk at the shipping port.
Q: What's your term of the delivery?
A: Our ordinary delivery term is FOB Shanghai.
We also accept EXW, CFR, CIF, DDP, DDU etc.
We'll offer you the shipping charges and you can choose the one which is the most convenient and effective for you.
Q: What about the lead time for mass production?
A: Honestly, it depends on the order quantity and the season you place the order.
Always 15-30 days based on general order .
